1.27mm Female Dual Row Header Connector SMT PA9T BK H=3.5 G/F

  • 1
  • 2

Brand Name : WCON

Model Number : 2335-2XXMG0CUNXX1

Certification : UL/SGS/ROHS

Place of Origin : China

MOQ : 1000pcs

Price : negotiaiton

Payment Terms : T/T

Delivery Time : 15-25Day

Packaging Details : Tube Reel

Supply Ability : 800000Kpcs

Current Rating : 1.0AMP

Withstand Voltage : 500V AC/DC

Characteristics : Side Entry Type W/0 post or W/T post

Plastic height : H=3.5

Port : Hong Kong

Export mode : FOB Or FCA Based on order Amount

Contact Now

1.27mm Female Header Connector double row SMT PA9T BK H=3.5 G/F.

Current Rating 1.0AMP
Contact Resistance 20mΩ Max
Withstand Voltage 500V AC/DC
Insulation Resistance 1000mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material phosphor Bronze
Contact Plating AU over Ni
Insulator Material PA9T+30％GF UL94V-0

Item name: female connector:

1.product features: the use of a wide range of environmental protection, high temperature, fire resistance, oxidation resistance.

2.product material: PA9T/PBT/ brass or phosphor bronze insulation material: plastic UL 94V-0.

3.scope of application: widely used in electronics, electrical appliances, instruments in the general connection of the main components of the current or signal transmission. Usually with the needle supporting the use of a board to board connection. The utility model is matched with an electronic wiring harness terminal to form a board to wire connection.

1.27mm Female Dual Row Header Connector SMT PA9T BK H=3.5 G/F

1.27mm Female Dual Row Header Connector SMT PA9T BK H=3.5 G/FDrawing:Female Header 2335-2XXMXXCUNX1.pdf
